1 Channel Infrared Tracking Sensor
₦ 1,500This is 1 Channel Infrared Tracking Sensor from the category Sensors | Infrared/Distance.
Product Specifications:
- 1. Utilizing the TCRT5000 infrared reflection sensor
- 2.Applicable detection reflection distances of 1 mm to 25 mm
- 3. A 5V operating voltage
- 4. Digital signals as the output format (0 and 1)
- 5.Easy to install; fixed bolt hole.
- 6.3.5 x 1 cm is the small board PCB size.
Application:
- 1.Sampling of pulse data from power metres
- 2. Paper detection for fax machines
- 3. Detection impediment
- 4. Detection of black and white lines
Package Included:
- Infrared tracking sensor with one channel is included in the package.
Qucik View -
20g Speed Measurement Code Disc (5pcs)
₦ 1,000Speed Code Disc 20 Grid TT Motor Wheel Speed Counting Code Disk High Precision Laser Processing Product introduction. The speed measuring code disc is specially used for measuring the speed of the straight bar type reduction motor. The distance and speed of the car body movement are calculated by calculating the number of spaces after rotation.
Feature:
- Name: Speed code disc
- Number of spaces: 20
- Diameter of code disc: 26mm
- Code disc thickness: about 3.6mm
- Center aperture: about 3.5 * 5.4mm
- Material: plastic
- Purpose: TT motor, reduction current
Package Includes:
5 x Speed Measurement Code Disk 20 GridQucik View -
8-Channel Digital Capacitive Switch Touch Sensor Module For Arduino – TTP226
₦ 4,050A capacitive touch module which sends out signals on contact, it can be interfaced to an Arduino or any microcontroller. This module can be used to build all kinds of interesting projects from access control, home automation, automotive projects etc
- Onboard TTP226 capacitive 8 keys touch sensor IC
- Onboard 8 channel level status indicator
- Working voltage: 2.4V-5.5V
Qucik View -
ADXL335 3-Axis Analog Output Accelerometer Sensor
₦ 7,500The ADXL335 3-Axis Analog Accelerometer is excellent for your drone and motion sensing projects. With a very simple 3-axis analog output, it has a minimal I/O requirement.
- 3-axis sensing
- Small, low-profile package
- Low power – 350 μA (typical)
- Single-supply operation
- 1.8 V to 3.6 V
Can withstand up to 10,000 g shock
Qucik View -
Body Scale/Load Sensor 50kg
₦ 1,500This load sensor, sometimes called a strain gauge, is the same one found in digital bathroom scales (you know, the ones you use in January for your New Year’s resolutions, and then forget about a month later). This sensor can measure up to about 110 pounds.
Qucik View -
Bosch BMP180 Barometer Pressure/Temperature/Altitude Sensor (Arduino Compatible)
₦ 1,500The BMP180 is a precision barometric pressure, temperature and altitude sensor from manufactured by Bosch. It is fully compatible with BMP085 in terms of firmware/software/interfacing. BMP180 can easily be configured to work with Arduino, ARM or PIC over I2C.
Specification
- 3-5V Logic and Power
- Pressure sensing range: 300-1100 hPa (9000m to -500m above sea level)
- Up to 0.03hPa / 0.25m resolution
- -40 to +85°C operational range, +-2°C temperature accuracy
- This board/chip uses I2C 7-bit address 0x77.
Arduino sample code: //www.haoyuelectronics.com/Attachment/GY-68/bmp085_arduino.zip
Datasheet: //cdn-shop.adafruit.com/datasheets/BST-BMP180-DS000-09.pdf
Product InformationBrandQucik View -
Collision Switch Module
₦ 1,500The Collision Switch Module is used to detect a collision with an object or to detect the limit of travel.
PACKAGE INCLUDES:
Collision Switch Module
KEY FEATURES OF COLLISION SWITCH MODULE:
Detect collisions with an object on robotic vehicles
Use as travel limit switch on 3D printers and similar applications
LED Lights when switch is engaged
Compatible with 3.3 and 5V logic
This switch module is often called a collision or crash switch, as it is sometimes used to detect when a robotic vehicle makes contact with an object. They are also used as limit switches to detect when something such as a 3D printer head has reached the limit of its travel.The module mounts a small microswitch with a lever. The output is normally held HIGH via a 10K pull-up resistor on the module. When the switch lever is depressed, the output is pulled to ground and goes LOW and the LED on the module lights.
The switch body is rated for up to 2A @ 125VAC, but the module is designed to switch logic level signals.
Module Connections
1×3 HeaderOUT = Output is normally HIGH. The output goes LOW when switch is depressed
VCC = Power. Typically kept at 3.3 or 5V to match the MCU it is used with
GND = Ground which should be common with the MCU.
The module has one M3 hole for mounting.Qucik View -
DHT11 TEMPERATURE SENSOR
₦ 2,500The DHT11 is a low-cost and reliable digital temperature and humidity sensor. Digital output only. It is compatible with Arduino complete with library as well as other microcontrollers.
- 3 to 5V Operating range
- 2.5mA (max)
- 20-80% humidity readings (up to 5% accuracy)
- 0-50°C temperature readings (up to ±2°C accuracy)
- 1 Hz Maximum sampling rate
- 15.5mm x 12mm x 5.5mm
- 4 pins with 0.1″ spacing
Pins
1. VCC
2. Data
3. NC
4. Ground
Qucik View -
DHT22 Temperature and Humidity Sensor
₦ 10,500DHT-22 is a humidity and temperature sensor with read out over single wire digital interface. The sensor is already calibrated and doesn’t need extra components so you can measure relative humidity and temperature right away.
- 3 to 5V power and I/O
- 2.5mA max current use during conversion (while requesting data)
- Good for 0-100% humidity readings with 2-5% accuracy
- Good for -40 to 80°C temperature readings ±0.5°C accuracy
- No more than 0.5 Hz sampling rate (once every 2 seconds)
Qucik View -
Digital Capacitive Touch Sensor – TTP223B
₦ 3,000This device allows you to add touch functionality to your designs. It can be easily interfaced with an Arduino or other microcontroller GPIO pins.
Features:
- Operating Voltage: 2-5V
- Chip: TTP223B
- Response Time: 60-220ms
- PCB Size: 28x20mm
- Fully Arduino Compatible
Qucik View -
DS18B20 Waterproof Temperature Sensor – Arduino Compatible
₦ 2,000The DS18B20 allows you take temperature readings in water or oils within its specified temperature range.
DS18B20 Technical specs:
- Usable temperature range: -55 to 125°C (-67°F to +257°F)
- 9 to 12 bit selectable resolution
- Uses 1-Wire interface- requires only one digital pin for communication
- Unique 64 bit ID burned into chip
- Multiple sensors can share one pin
- ±0.5°C Accuracy from -10°C to +85°C
- Temperature-limit alarm system
- Query time is less than 750ms
- Usable with 3.0V to 5.5V power/data
Work with Arduino IDE on ESP8266 Wifi module to take temperature readings over the Internet: //iot-playground.com/blog/2-uncategorised/41-esp8266-ds18b20-temperature-sensor-arduino-ide
Qucik View -
DS18B20 Waterproof Temperature Sensor Kit
₦ 4,000The DS18B20 allows you take temperature readings in water or oils within its specified temperature range.
DS18B20 Technical specs:
- Usable temperature range: -55 to 125°C (-67°F to +257°F)
- 9 to 12 bit selectable resolution
- Uses 1-Wire interface- requires only one digital pin for communication
- Unique 64 bit ID burned into chip
- Multiple sensors can share one pin
- ±0.5°C Accuracy from -10°C to +85°C
- Temperature-limit alarm system
- Query time is less than 750ms
- Usable with 3.0V to 5.5V power/data
Work with Arduino IDE on ESP8266 Wifi module to take temperature readings over the Internet: //iot-playground.com/blog/2-uncategorised/41-esp8266-ds18b20-temperature-sensor-arduino-ide
Qucik View
