M04 Water Level Detection Module

The M04 Water Level Module is a simple and compact sensor designed to detect water levels through a series of parallel exposed traces. It converts the water level into an analog signal, making it ideal for water tanks, rain detection, and automated irrigation systems. Its straightforward design makes it easy to integrate into microcontroller-based projects for real-time water monitoring.

Features:

• Analog Output: Converts water level to voltage
• Simple Interface: Easy connection to microcontrollers
• Corrosion-Resistant PCB: Prolongs lifespan in wet conditions
• Compact Design: Fits into narrow tanks or small setups
• Low Power Consumption: Ideal for battery-powered systems

Specification:

• Model: M04
• Operating Voltage: DC 3.3V – 5V
• Output Type: Analog voltage signal
• Sensing Method: Exposed PCB traces
• Detection Range: Full height of sensor board
• Dimensions: ~65 mm × 20 mm
• Weight: ~5 g

Application:

• Water tank level monitoring
• Rainwater detection systems
• DIY irrigation control
• Smart agriculture solutions
• Leak detection for appliances or aquariums
