HXJ8002 Mini Amplifier Module


SKU: 171-1-1-1


The HXJ8002 Mini Amplifier Module is the best option for small-space audio amplification requirements. With its compact design and potent amplification capabilities, this state-of-the-art module is perfect for a variety of uses, including DIY audio projects, portable speakers, and headphone amplifiers.

Without sacrificing performance, the HXJ8002 Mini Amplifier Module reproduces sound crystal clear thanks to its high-quality audio output, little distortion, and economical power usage. This flexible module will take your audio experience to new levels whether you’re a professional or a hobbyist. Prepare to enhance your audio endeavors by utilizing the HXJ8002 Mini Amplifier Module.

This miniature audio amplifier module is ideal for adding audio output capabilities to your new project. It is based on the HXJ8002 single channel 3 W BTL power audio amplifier chip, which features a low harmonic distortion of the audio signal.


  • Compact and mini-sized amplifier module
  • High-quality audio amplification
  • Ideal for DIY projects
  • Easy connectivity
  • Efficient power usage
  • Enhances audio output
  • Perfect for portable speakers
  • Upgrade existing audio equipment


  • On-board HXJ8002 chip
  • Number of channels: single
  • Output power: 3 W (for a 3 load), 2.5 W (4 load), 1.5 W (8 load)
  • Working Voltage Range: 2 V to 5.5 V
  • Standby Current: 0.6 (typical value)
  • Board Size: 19.8 x 14.2 mm

Package Includes:

  • 1 x HXJ8002 Mini Amplifier Module


  • //www.openimpulse.com/blog/wp-content/uploads/wpsc/downloadables/HXJ8002-Miniature-Audio-Amplifier-Datasheet.pdf
