ESP32-C6-N16R8-DevKit 16MB Flash (WiFi+Bluetooth)

The ESP32-S3 N16R8 Core Development Board is a cutting-edge, versatile microcontroller platform built around the ESP32-S3-WROOM module, delivering robust performance for loT, embedded, and wireless applications. Powered by a dual-core Xtensa LX7 processor with up to 240 MHz clock speed, it features integrated WiFi and Bluetooth capabilities, ample onboard storage, and compatibility with popular programming frameworks like ESP-IDF, MicroPython, and Arduino. Equipped with a CH340K USB-to-serial interface for fast and stable connections, this board is ideal for developers and hobbyists looking to create high-performance loT solutions.

Features:

1. Powerful Performance:

• Dual-core Xtensa LX7 CPU with up to 240 MHz and advanced 128-bit data bus architecture.
• Exceptional processing power with CoreMark scores of up to 1181.60 for dual-core configurations.

2. Wireless Connectivity:

• WiFi: IEEE 802.11b/g/n with support for 20 MHz and 40 MHz bandwidths in the 2.4 GHz range.
• Bluetooth: Bluetooth 5 LE with high power mode and Bluetooth Mesh support.

3. Ample Storage:

• Includes 16MB Flash and 8MB PSRAM for complex programs and real-time data handling.
• Backward-compatible with lower storage configurations like N4, N8 modules.

4. Flexible Programming Options:

• Compatible with ESP-IDF, Arduino IDE, and MicroPython for seamless development.
• Supports multiple development environments on Windows, Linux, and macOS.

5. Rich Interface Options:

• SPI, DualSPI, QuadSPI, and OctalSPI interfaces for memory expansion.
• USB CH340K interface supporting up to 2 Mbps data rate.

6. Efficient Power Management:

• Supports low-power modes for energy-efficient loT deployments.
• Integrated RTC with 16KB SRAM for real-time applications.

7. Development Friendly:

• Offers detailed online resources, tutorials, and example projects for easy onboarding.
• USB interface and baud rate compatibility up to 115200 for reliable programming.

Specifications:

Processor and Storage:

• CPU: Dual-core Xtensa LX7, 240 MHz
• Flash: 16MB
• PSRAM: 8MB
• ROM: 384KB
• SRAM: 512KB
• RTC SRAM: 16KB

Wireless:

• WiFi: IEEE 802.11b/g/n, up to 150 Mbps
• Bluetooth: Bluetooth 5 LE with speeds up to 2 Mbps

Interface:

• USB-to-Serial: CH340K, max rate 2 Mbps I/O Interfaces: SPI, UART, 12C, PWM, ADC, DAC

Power Supply:

• Input Voltage: 5V via USB
• Low-Power Modes: Supported for extended battery life

Dimensions:

• Compact and lightweight, suitable for embedded applications.
